  • the "tiemuniu" unmanned transport robot adopts a multifunctional chassis that can be towed or pulled. it can be used in various fields such as factories, automobile manufacturing, ports, and food. it adopts a multi-source fusion navigation mode to achieve all-weather and full-function unmanned transport.
  • the "tiemuniu" unmanned transport robot has the functions of three-dimensional laser positioning navigation, autonomous obstacle avoidance, automatic charging, free route planning, and multi-vehicle intelligent dispatch.
    • it can operate at high frequencies all day long without being affected by the weather, adapting to various complex indoor and outdoor scenes.
    • with multi-sensor fusion slam technology for positioning and navigation, it does not require the laying of tracks or landmarks, and the positioning accuracy can reach centimeter level.
    • it can carry out autonomous route planning, update the route planning when encountering obstacles, and change parking points and logistics transportation routes.
    • it supports rapid generation of operational maps and map editing, real-time monitoring of changes in the operating environment, and updating and synchronization of maps.
    • when the power is lower than the preset alarm threshold, it can automatically return to the charging room for charging. adopting wireless charging and super capacitor technology, the charging time is short.
    • the system is equipped with a multi-machine task intelligent scheduling algorithm, which selects the optimal target according to the robot's current task load, location and power, improving task execution efficiency.
    • it supports the integration display of three-dimensional models, iot devices, robot operation processes, production data on a large screen, providing a basis for intelligent management decisions.
    • iot interface adaptation is available, which supports real-time access, visual analysis, and remote control of robots, robotic arms, video monitoring, environmental sensors, access control, and other devices.
    • 01
      efficient &flexible &convenient
      it can seamlessly connect with enterprise erp, mes, and other internal systems to achieve automated transfer of goods indoors and outdoors, saving labor costs, and reducing costs while increasing efficiency for enterprises.
    • 02
      laser slam navigation
      it is equipped with self-developed robot autonomous positioning and navigation system, multi-sensor fusion and positioning algorithm, front anti-collision bar and surrounding ultrasonic radar, emergency stop button and abnormal alarm, which can construct a comprehensive safety system.
    • 03
      digital twin
      it can build a high-precision three-dimensional twin map of the factory area through the digital twin true map platform, and realize the operation situation supervision of the factory area on one screen, to help intelligent management and decision-making.
    • 04
      high return on investment and more cost-effective
      the robot can bring higher efficiency and lower costs to enterprises, and has high returns on investment, which can bring continuous benefits to enterprises.
    application value
    the robot is available for scenarios such as final assembly logistics, engine logistics, stamping logistics, and body logistics in automotive manufacturing bases. the variety of parts and packaging sizes makes it difficult to distribute logistics due to the inconsistent packaging forms and sizes. using unmanned tractors can minimize the disruption of the original distribution mode and upgrade it in a more traditional way, while reducing the cost of factory tooling modifications, ultimately achieving perfect coexistence and collaboration with traditional manual logistics.
    application value
    the robot can accomplish automatic transformation of loading and unloading, transportation, distribution, and warehousing in the factory and industrial park, as well as the transfer of goods between warehouses and workshops. through precise task scheduling, route planning, remote monitoring, and cloud scheduling, the unmanned operation in the industrial park is completed, making logistics transportation safer, more efficient, and lower-cost, improving the operational efficiency of the industrial park.
    application value
    the robot can be applied to scenarios such as intelligent warehousing, flexible handling, intelligent picking and intelligent logistics, and throughout all aspects of warehousing, production and distribution. it can be customized for the whole factory intelligent manufacturing solutions.
    basic performance
    dimension
    2900*1800*750(mm)
    transportation method
    backpack
    wheelbase
    850mm
    navigation method
    multi-source fusion navigation (3dslam rtk imu)
    carrying capacity
    800kg
    postioning navigation accuracy
    ≤10cm
    minimum turning radius
    ≤3cm
    maxium obstacle clearance height
    ≥80mm
    maxium water crossing depth
    ≥100mm
    maxium crusing speed
    ≤18km/h
    maxium climbing angle
    ≥10°(full load)
    endurance time
    ≥8 hours(50% full load/50% empty load,at a spped of 1.5m/s)
    battery
    48v/40ah
    charging time
    ≤4 hours(20%~90%)
    charging method
    automatic/manual
    protection level
    ip54
    operating temperature
    -20℃` 50℃
    basic performance
    size
    2156*1546*616(mm)
    maximum transport capacity
    500kg(bearing)
    how to navigate
    multi-source fusion navigation(3dslam rtk imu)
    positioning navigation accuracy
    ≤10cm
    ixed-point docking accuracy
    ≤3cm
    battery life
    8 hours (customizable)
    operating temperature
    -20℃~50℃
    athletic performance
    maximum travel speed
    40km/h
    obstacle crossing height
    200mm
    security protection
    blind spot detection and obstacle awareness

    collision detection

    emergency stop button

    protection level

    ip54

    applicable scenarios
    indoor and outdoor load and traction transportation


    basic performance
    size
    1800*720*1500(mm)
    maximum transport capacity
    100kg(bearing)
    how to navigate
    multi-source fusion navigation(3dslam rtk imu)
    positioning navigation accuracy
    ≤10cm
    fixed-point docking accuracy
    ≤3cm
    battery life
    8hour(customizable)
    operating temperature
    -20℃~50℃
    athletic performance
    maximum travel speed
    20km/h
    obstacle crossing height
    50mm
    security protection
    blind spot detection and obstacle awareness

    collision detection

    emergency stop button

    protection level
    ip54
    applicable scenarios
    indoor and outdoor load and traction transportation
